Industry Best: Nu-Ray Metal Roofing

Nu-ray Metal Roofing is a Pacific Northwest based manufacturer of metal roofing, siding and trims. With over 100 yrs of combined experience and over 60,000 sf. of custom manufacturing facilities in WA state and CA, Nu-ray Metal Roofing produces the best metal roofing materials available in the Seattle area.

Three Tree Roofing is proud to the exclusively offer Nu-Ray Metals as our metal. We have a great working relationship with Nu-Ray Metals and work closely with them during the fabrication process. We have all of our metal panels made in the factory with their calibrated roll machines. Nu-Ray Metal has two warranty options, 40 year and 50 year warranty options. Three Tree Roofing offers a 25 year workmanship warranty on all metal roof installs. If your looking for a long lasting, top quality metal roof, make sure you have Three Tree Roofing install your metal roof.





Roofing Product Overview: NuRay Metal Roofing Product Lines

Click here for more about metal roofing: 5 Different Types Of Roofs: Metal Roofing.

Below are details for each of the Nu-Ray Metal Roofing Materials we offer in Seattle.

Quick Links:


NRM-5000/NRM-6000

Durable, Long Lasting Metal Roofing

The NRM-5000 and 6000 panels are designed to provide durable, long lasting roofing solutions. One piece design of the snap lock panel makes it easy for quick installation while minimizing labor involved in rolling up your next large order! Snap-lock panels are to be factory roll-formed in continuous lengths. Maximum length is 44’ 0˝ and minimum length is 4’ 0˝.

Standard panel widths are 12˝ (NRM-5000) and 16˝ (NRM-6000). Optional pencil ribs or striations can be added at no additional cost.

Fasteners - For roofing applications, use wood-type screws fastened on 24˝ centers. Other screw types are available applications over structural steel and steel decking.

Trim - All flashing and trim shall be fabricated by Nu-Ray Metals or a qualified fabricator. Flashings for this panel shall be 26 or 24 gauge steel.

Installation - For roofing applications, Nu-Ray’s snap-lock panels shall be installed over solid decking (5⁄8˝ plywood, nailboard insulation or equivalent, with an underlayment of 30# roofing felt applied horizontally from eave to ridge.) Panels shall be fastened on 24˝ centers (max.). Minimum roof pitch is 3:12.

Handling - Vinyl masking is provided on all steel sheet to help protect materials where extra handling is expected.

Warranty - A 40-year non-prorated finish warranty can be supplied covering finish performance.

Metal Roof Replacement featuring Three Tree Roofing metal roofing

Our Three Tree Roofing Metal Roofer Specialist are experts in Nu-Ray Metal Roofing installation. This was a Gorgeous New Metal Roof Replacement in Woodinville, Washington.

Features
  • Excellent panel for architectural, commercial and industrial roof, mansard, canopy and fascia applications
  • Snap-lock design
  • Great load and span capacities
  • Apply over open framing or solid substrates
  • Long-length crating available
  • Minimum 3:12 roof pitch
  • UL 580 Class 90 Rated and Listed

Nu-Ray Metal Roofing, NRM-5000/6000, Close up view

This is a close up view of the Nu-Ray NRM-5000 & NRM-6000 Snap-Lock Concealed Fastener Panel in Redi-Mix Red (SRI-44).

Nu-Ray Metal Roofing, NRM-5000/6000, Technical Diagram

This is a technical diagram of the Nu-Ray NRM-5000 & NRM-6000 Snap-Lock Concealed Fastener Panel.

Technical Information

Panel Depth:

Panel Cover Width: 12˝ (NRM-5000) and 16˝ (NRM-6000)

Panel Lengths: 4’ 0˝ to 44’ 0˝ standard

Metal Options

  • 24 and 26 gauge G90 or AZ50 steel
  • 16 oz. or 20 oz. natural copper (special order)

Surface Options

  • 3 pencil ribs (12˝ NRM-5000 panel)
  • 4 pencil ribs (16˝ NRM-6000 panel)
  • Striations

Finishes

  • D2 Kynar 500® ULTRA-Cool™
  • D2 Kynar 500® with Ocean Guard ULTRA-Cool™
  • Zincalume Plus*
  • Standard Kynar 500® ULTRA-Cool™
Downloads
▲   Back to Menu

NRM-1000

The Classic Metal Roofing

NRM-1000 is an architectural metal roofing system available exclusively from Nu-Ray Metal Products. It is intended for applications over a solid substrate with a minimum 3:12 roof pitch. Typical substrates include plywood, nailboard insulation or equivalent. Panels are factory roll-formed in continuous lengths. Standard panel length is 4’ 0˝ to 44’ 0˝. For longer lengths, please contact us.

NRM-1000 roof panels feature a concealed attachment clip system to allow thermal movement as panels expand and contract with temperature changes. With its custom design, the clip insures an extra-snug fit. The one-piece design of the NRM-1000 clip makes installation easy.

Fasteners - For roofing applications, use wood-type screws fastened on 18˝ centers. Other screw types are available applications over structural steel and steel decking.

Trim - All flashing and trim shall be fabricated by Nu-Ray Metals or a qualified fabricator. Flashings for this panel are 26 or 24 gauge steel.

Installation - For roofing applications, Nu-Ray’s snap-lock panels shall be installed over solid decking (5/8˝ plywood, nailboard insulation or equivalent) with an underlayment of 30# (minimum) roofing felt applied horizontally from eave to ridge. Panels shall be fastened via attachment clip spaced on 24˝ centers (maximum). For wider clip spacing, please contact us.

Handling - Vinyl masking is provided on all steel sheet to help protect materials where extra handling is expected.

Warranty - A 40-year non-prorated finish warranty can be supplied covering finish performance.

Duvall Metal Roof

Link label caption.

Features & Benefits
  • Excellent panel for architectural, commercial and industrial roof applications
  • Narrow rib design
  • Great load and span capacities
  • Apply over open framing or solid substrates
  • Long-length crating available
  • Minimum 3:12 roof pitch
  • UL 580 Class 90 Rated and Listed

Nu-Ray Metal Roofing, NRM-1000, Close up view

Link label caption.

Nu-Ray Metal Roofing, NRM-1000, Technical Diagram

Link label caption.

Technical Information

Panel Depth: 1½˝

Panel Cover Width: 12˝ or 16˝

Panel Lengths: 4’ 0˝ to 44’ 0˝ standard; check with Nu-Ray Customer Service for longer lengths.

Metal Options

  • 24 and 26 gauge G90 or AZ50 steel
  • .032 and .040 aluminum (special order)
  • 16 oz. or 20 oz. natural copper (special order)

Surface Options

  • Smooth/flat
  • Two pencil ribs
  • Striations

Finishes

  • D2 Kynar 500® ULTRA-Cool™
  • D2 Kynar 500® with Ocean Guard ULTRA-Cool™
  • Zincalume Plus*
  • Standard Kynar 500® ULTRA-Cool™
Downloads
▲   Back to Menu

NRM-1750

Outperforms All Others

NRM-1750 panels combine architectural panel aesthetics with structural panel performance. The panel is produced in continuous lengths. Optional factory-applied seam sealant improves weather resistance. Factory eave notching aids in installation of hook eave flashing. Standard panel length is 4’ 0˝ to 44’ 0˝. On-site forming is available for longer lengths; For longer lengths, please contact us.

NRM-1750 features 1¾˝ leg height and continuous interlock for enhanced structural performance and wind resistance. A concealed clip system allows thermal expansion/contraction while providing extraordinary hold-down strength. Two clips are available: a standard clip for mansard and fascia applications; and a high performance clip for UL 90 Rated roof installations.

Fasteners - For roofing applications, use wood-type screws fastened on 36˝ centers. Other screw types are available applications over structural steel and steel decking.

Trim - All flashing and trim shall be fabricated by Nu-Ray Metals or a qualified fabricator. Flashings for this panel are 26 or 24 gauge steel.

Installation - For roofing applications, Nu-Ray’s 1750 panels shall be installed over solid decking (5/8˝ plywood, nailboard insulation or equivalent) with an underlayment of 30# (minimum) roofing felt applied horizontally from eave to ridge. Panels shall be fastened via attachment clip spaced on 36˝ centers. For wider clip spacing, please contact us. Minimum roof pitch is 2:12 (factory-injected seam sealant required).

Handling - Vinyl masking is provided on all steel sheet to help protect materials where extra handling is expected.

Warranty - A 40-year non-prorated finish warranty can be supplied covering finish performance.


Link label caption.

Features & Benefits
  • Excellent panel for architectural, commercial and industrial roof applications
  • Factory-injected seam sealant available as an option
  • Great load and span capacities
  • Apply over open framing or solid substrates
  • Factory notching (13⁄8˝) available as an option
  • Minimum 2:12 roof pitch
  • UL 580 Class 90 Rated and Listed

Nu-Ray Metal Roofing, NRM-1750, Close up view

Link label caption.

Nu-Ray Metal Roofing, NRM-1750, Technical Diagram

Link label caption.

Technical Information

Panel Depth: 1¾˝

Panel Cover Width: 14˝, 16˝, 17˝ or 18˝ (14˝ and 18˝ standard)

Panel Lengths: 4’ 0˝ to 44’ 0˝ standard. On-site forming available for longer lengths.

Metal Options

  • 22 (special order), 24 and 26 gauge G90 or AZ50 steel
  • .032 and .040 aluminum (special order)
  • 16 oz. or 20 oz. natural copper (special order)

Surface Options

  • Smooth/flat
  • Two pencil ribs
  • Striations
  • Pencil ribs

Finishes

  • D2 Kynar 500® ULTRA-Cool™
  • D2 Kynar 500® with Ocean Guard ULTRA-Cool™
  • Zincalume Plus*
  • Standard Kynar 500® ULTRA-Cool™
Downloads
▲   Back to Menu

NRM-2000 (24 or 26 Gauge)

Best for Low-slope Roofs

NRM-2000 panels are ideal for low-slope applications, combining structural panel performance with architectural panel aesthetics. Optional factory-applied seam sealant can be applied for additional weather resistance on low-slope applications. Maximum panel length is variable as Nu-Ray has the capability to form continuous panels on site for long roof sections. Maximum factory-formed panel length is 44’ 0˝. Minimum panel length is 4’ 0˝.

NRM-2000 features 1½˝ leg height that requires mechanical field seaming after installation. The panel employs a concealed-fastener floating clip system that allows thermal expansion/contraction.

Fasteners - Panel shall be fastened via attachment clip spaced on 24˝ centers; for wider clip spacing, please check with Nu-Ray Customer Service. Other screw types are available applications over structural steel and steel decking.

Trim - All flashing and trim shall be fabricated by Nu-Ray Metals or a qualified fabricator. Flashings for this panel shall be 26 or 24 gauge steel.

Installation - NRM-2000 panels are intended for use in architectural and structural roofing. Substrates include 5⁄8˝ plywood, nailboard insulation or equivalent, with an underlayment of 30# roofing felt applied horizontally from eave to ridge. Other substrates may include metal decking, purlins or rigid insulation in conjunction with bearing plates. Minimum roof pitch is ½:12. Factory-injected seam sealant is required on pitches less than 2:12.

Handling - Vinyl masking is provided on all steel sheet to help protect materials where extra handling is expected.

Warranty - A 40-year non-prorated finish warranty can be supplied covering finish performance.

Bellevue metal roofing by Three Tree Roofing

Link label caption.

Features & Benefits
  • Superb panel for architectural, commercial and industrial roof applications
  • Factory-injected seam sealant available as an option
  • Great load and span capacities
  • Apply over open framing or solid substrates
  • On site forming available
  • Minimum ½:12 roof pitch
  • UL 580 Class 90 Rated and Listed

Nu-Ray Metal Roofing, NRM-2000, Close up view

Link label caption.

Nu-Ray Metal Roofing, NRM-2000, Technical Diagram

Link label caption.

Technical Information

Panel Depth: 1½˝

Panel Cover Width: 12˝ or 16˝

Panel Lengths: 4’ 0˝ to 44’ 0˝ standard; on-site forming available for longer lengths.

Metal Options

  • 22 (special order), 24 and 26 gauge G90 or AZ50 steel
  • .032 and .040 aluminum (special order)
  • 16 oz. or 20 oz. natural copper (special order)

Surface Options

  • Smooth/flat
  • Two pencil ribs
  • Striations
  • Pencil ribs

Finishes

  • D2 Kynar 500® ULTRA-Cool™
  • D2 Kynar 500® with Ocean Guard ULTRA-Cool™
  • Zincalume Plus*
  • Standard Kynar 500® ULTRA-Cool™
Downloads
▲   Back to Menu

Warranty Details

All Nu-ray products are covered by an industry-best warranties based on the product covered. Individual product warranties may vary in specific details and limitations.

▲ Back to Menu

About Nu-ray Metal Roofing

Nu-Ray is a family-owned business focused on helping one customer at a time with the aim of exceeding the customer's expectations. With over 100 yrs of combined experience, they offer technical assistance not found in many companies and their in-house technical service teams pride themselves on being the friendly and knowledgeable people.

Throughout the century, Nu-Ray has built over 60,000 sf. of custom manufacturing facilities in WA state and CA and today, are big enough to handle any size job. They take care of all customers big and small. Their state-of-the-art equipment features high speed, computer controlled roll formers with operators who each bring at least 20 years of experience to the job. They own a fleet of trucks delivering orders both locally and long distance. Their mobile forklifts navigate in four directions that enable delivery of long panel lengths to almost any job site.

You will always find Nu-Ray on the cutting edge of the industry, adopting and refining new technologies, new paint systems, and new ideas that improve the quality of their products and service.


Nu-ray Metal Roofing Exclusively Offer by Three Tree Roofing

If you have any questions about Nu-ray Metal Roofing Products for your home's roof or you want to know more about the Nu-ray Metal Roofing Warranties or the Three Tree Roofing Warranty, please contact us online or feel free to call us at 206.312.7663 (ROOF).
